Power Output |
1050W RMS Max. 800W RMS at 10%THD |
|
750W RMS at 5% THD 700W RMS at 2% THD |
Output Regulation |
2dB no load to full load at 1kHz |
Input Channels |
1×Mic 1mV/4.7k (Mic source impedance 50 to 1k) |
|
1×Aux 100mV/470k 1×Aux 250mV/20k |
|
1×CD 250mV/20k Line Input 1V/10k |
Digital Player |
MP3 Player with Remote Control (USB, SD and MMC Card Reader) |
Frequency Response |
50Hz–18,000Hz ±3dB |
Signal to Noise Ratio |
60dB |
Tone Controls |
Bass (100Hz) : ± 8dB Treble (10kHz) : ± 8dB |
Line Output |
1V/1k |
Output Taps for Speaker Matching |
2, 4 & 8 |
Power Supply |
AC: 220-240V 50/60Hz |
Protections |
2 × 25 Amp fuse in ± DC supply 8 Amp circuit breaker in AC mains |
|
Protected against high AC mains voltage, overload and temperature |
AC Power Consumption |
1500VA |
Dimensions |
W482 × H186 × D530 mm |
Weight |
32.0 kg |
