| Stereo/Mono |
8 650W + 650W RMS, 4 900W+900W RMS |
|
2 1250W+1250W RMS |
| Bridged Output |
8 1800W RMS, 4 2500W RMS |
| Single Channel Driven Output |
8 700W RMS, 4 1000W RMS, 2 1350W RMS |
| THD + N |
0.5% |
| Frequency Response (-1dB) |
20-20,000Hz |
| Power Bandwidth (0.5% THD) |
20-20,000Hz |
| Input Sensitivity |
0dBm (775mV) & 4dBm (1.24V) |
| Input Impedance |
10k Unbalanced, 20k Balanced |
| S/N Ratio |
95dB |
| Channel Separation |
65dB at 1kHz |
| Damping Factor |
400 : 1 (8) |
| Slew Rate |
35V/s |
| Protections |
Temperature, DC, RFI, Short Circuit, Overload, |
|
AC over voltage, Built-in limiter |
| Input Connectors |
2 × XLR, Stereo Phone Jack 6.3mm |
| Output Connectors |
Speakon 4-Way, Heavy Duty Screw Terminals each channel |
| Cooling |
Variable Speed DC Fan with Temperature Sensing |
| Front Panel Controls |
2× 21 Step Level Attenuators |
| Indicators |
ON, Signal, Clip, Temperatures, Protect (Ch. A & B) |
| Power Consumption |
3000VA @ 240V / 50Hz |
| Dimensions |
W482 × H153 × D555mm |
| Weight |
32.7kg |
