• 6 Mic & 2 Aux Inputs.
  • Preamplifier and Line Output for connecting to a Booster Amplifier and for recording the programme.
  • Line Input for connecting the output from any external mixer or permitting SSA-250 to be used as a Booster Power Amplifier.
  • Resettable circuit breaker for protection against overload and short circuit.
  • Instant transfer to DC power (Car Battery) if AC power fails.
  • Box Speaker/Driver Unit selector switch. Bass boost defeated at Driver Unit position for safer operation of driver units.
 Power Output 300W Max., 250W RMS at 10% THD
  220W RMS at 5% THD, 200W RMS at 2% THD
 Output Regulation 2 dB, no load to full load at 1kHz
 Input Channels 6 × Mic 0.65mV/4.7k, 2 × Aux 100mV/470 k
  1 × Line 1V/50k
 Frequency Response 50-15,000Hz ±3dB
 Signal to Noise Ratio 60dB
 Tone Controls Bass: ±10dB at 100Hz, Treble: ±10dB at 10kHz
 Outputs Preamp 200mV/600, Line 1V/1k
 Speaker Outputs 4, 8, 70V & 100V
 Power Supply AC: 220-240V 50/60Hz DC: 24V (2×12V Car Battery)
 Power Consumption AC: 460VA DC: 6A
 Dimensions W450 × H160 × D340 mm
 Weight 16.0kg
Back view
