• 3 Mic & 1 Aux Inputs.
  • Preamplifier Output for connecting to a Booster Amplifier and for recording the programme.
  • Instant transfer to DC power (Car Battery) if AC power fails.
  • Cut type Bass & Treble Controls.
Power Output 64W Max., 45W RMS at 10% THD
  40W RMS at 5% THD, 30W RMS at 2% THD
 Output Regulation 2 dB, no load to full load at 1kHz
 Input Channels 3 × Mic 0.65mV/4.7k, 1 × Aux 100mV/470k
 Frequency Response 100-15,000Hz ±3dB
 Signal to Noise Ratio 60dB
 Tone Controls Bass: -10dB at 100Hz, Treble: -10dB at 10kHz
 Outputs Preamp 200mV/600
 Speaker Outputs 4, 8, 16 & 100V
 Power Supply AC: 220-240V 50/60Hz DC: 12V (12V Car Battery)
 Power Consumption AC: 110VA DC: 2A
 Dimensions W280 × H120 × D270 mm
 Weight 4.8kg
Back view
