• 5 Mic & 2 Aux Inputs.
  • Preamplifier Output for connecting to a Booster Amplifier and for recording the programme.
  • Cut type Bass & Treble controls.
  • Instant transfer to DC power (Car Battery) if AC power fails.
 Power Output 110W Max., 80W RMS at 10% THD
  75W RMS at 5% THD, 60W RMS at 2% THD
 Output Regulation 2 dB, no load to full load at 1kHz
 Input Channels 5 × Mic 0.65mV/4.7k, 2 × Aux 100mV/470k
 Frequency Response 65-15,000Hz ±3dB
 Signal to Noise Ratio 60dB
 Tone Controls Bass: -10dB at 100Hz, Treble: -10dB at 10kHz
 Outputs Preamp 200mV/600
 Speaker Outputs 4, 8, 16, 70V & 100V
 Power Supply AC: 220-240V 50/60Hz DC: 12V (12V Car Battery)
 Power Consumption AC: 180VA DC: 3A
 Dimensions W355 × H133 × D285 mm
 Weight 8.5kg
Back view
