| Transmitter |
|
| RF Output Power |
20mW (Max) |
| Carrier Frequency Range |
480-510Mhz |
| Modulation Mode |
FM |
| Microphone Element |
Condenser, Cardioid |
| Power requirement |
9V battery |
| Current consumption |
≤40mA |
| Controls |
Microphone on/Mute/Off switch |
| Indication |
LED (momentary glow for RF ON & Permanent glow for Low battery) |
| Dimensions |
W63 x H35 Xd100mm |
| Weight |
0.10 Kg (w/o battery) |
| Receiver |
| Carrier Frequency Range |
480-510Mhz |
| Audio Output |
Balanced 0-50mV |
| |
Unbalanced HI: 0-80mV; LO: 0-25mV |
| Distortion |
≤1% |
| Frequency Response (±3dB) |
50-15,000Hz |
| Power Requirement |
240V AC 50Hz for AC Adaptor (supplied alongwith) |
| Controls |
Power switch, HI/LO switch, Squelch control,Output volume control |
| Indications |
Red LED for Power, Yellow LEDs for Diversity, Green LED for Audio Peak |
| Dimensions |
W195 x H45 x D150 mm |
| Weight |
0.70Kg |
