• Input Channels : Each Channel has separate 1/4” balanced phone jack for Mic and Line & accepts both balanced & unbalanced signals.
  • AUX Control : This controls the level of the channel in the final mix to Aux Send output.
  • AUX Send & AUX Return : These have been provided for sending the pre-fader output of channels for monitoring or for adding a Special Effects Unit.
  • MONO/STEREO Output : Mono output is available from either Left & Right output jacks when the switch is in ‘Mono’ position.
Power Requirements AC: 220-240V 50/60Hz DC: 24v (2×12V Car Battery)
 MIC Input (Impedance/Gain) 2k/62dB
 LINE Input (Impedance/Gain) 20k Balanced/42dB, 10k Unbalanced/42dB
 Distortion < 0.08%
 Frequency Response 30Hz - 20kHz (+0, -1dB)
 Tone Controls Bass : ±12dB at 100Hz Mid : ± 12dB at 2kHz
  Treble : ± 12dB at 10kHz
 Outputs Line Output LO -10dBm/+2dBm (200mV/1V)
  Line Output HI 0dBm/+17dBm (775mV/5.5V)
 Echo/Reverb System Digital Signal Processing
 Signal to Noise Ratio >70dB (0dBm, 0.775V)
 Dimensions W633 × H93 × D420 mm
 Weight 9.4kg
