| Power Requirements |
AC: 220-240V 50/60Hz DC: 24v (2×12V Car Battery) |
| MIC Input (Impedance/Gain) |
2k/62dB |
| LINE Input (Impedance/Gain) |
20k Balanced/42dB, 10k Unbalanced/42dB |
| Distortion |
< 0.08% |
| Frequency Response |
30Hz - 20kHz (+0, -1dB) |
| Tone Controls |
± 12dB at 100Hz ± 12dB at 10kHz |
| Outputs |
Line Output LO -10dBm/+2dBm (200mV/1V) |
| |
Line Output HI 0dBm/+17dBm (775mV/5.5V) |
| Echo/Reverb System |
Digital Signal Processing |
| Signal to Noise Ratio |
>70dB (0dBm, 0.775V) |
| Dimensions |
W483 × H93 × D366 mm |
| Weight |
6.7kg |
