| Power Rating | 100W RMS |
| Nominal Diameter | 305 mm (12”) |
| Nominal Impedance | 8 |
| Sensitivity (1W/1m ) | 97dB |
| Magnet Weight | 1.1kg |
| Resonant Frequencey (Fs) | 70Hz |
| DC Resistance (Re) | 6.0 |
| Electromagnetic Q (Qes) | 0.79 |
| Mechanical Q (Qms) | 5.5 |
| Total Q Factor (Qts) | 0.69 |
| Compliance Equivalent Volume (VAS) | 74.23Litr |
| Surface Area of Cone (Sd) | 510 |
| Reference Efficiency (o) | 3.09% |
| Voice Coil | 1.5” |
| Overhang (Xmax) | 2.0 mm |
| Moving Mass (Mms) | 25.5gm |
| BL Product (BL) | 9.2TM |
| Overall Diameter | 311 mm |
| Depth | 130 mm |
| Baffle Hole Diameter | 285 mm |
| Bolt Mount Diameter (PCD) | 292 mm (8 Bolts) |
| Weight | 3.20kg |
