| Power Rating | 200W RMS |
| Nominal Diameter | 380 mm (15") |
| Nominal Impedance | 8 |
| Sensitivity (1W/1m ) | 98dB |
| Magnet Weight | 1.54kg |
| Resonant Frequency (Fs) | 45Hz |
| Nominal DC Resistance (Re) | 6.0 |
| Electromagnetic Q (Qes) | 0.58 |
| Mechanical Q (Qms) | 9.6 |
| Total Q (Qts) | 0.54 |
| Compliance Equivalent Volume (VAS) | 115 Litr |
| Surface Area of Cone (Sd) | 830 |
| Reference Efficiency (o) | 2.1% |
| Voice Coil Diameter | 2” |
| Overhang (Xmax) | 3.5 mm |
| Moving Mass (Mms) | 73gm |
| BL Product (BL) | 13.4TM |
| Overall Diameter | 385 mm |
| Depth | 165 mm |
| Baffle Hole Diameter | 355 mm |
| Bolt Mount Diameter (PCD) | 373 mm (8 Bolts) |
| Weight | 4.9kg |
