| Power Rating |
300W RMS |
| Nominal Diameter |
380mm (15”) |
| Nominal Impedance |
8 |
| Sensitivity (1W/1m ) |
99dB |
| Magnet Weight |
2.31kg |
| Resonant Frequencey (Fs) |
45Hz |
| DC Resistance (Re) |
5.75.7 |
| Electromagnetic Q (Qes) |
0.32 |
| Mechanical Q (Qms) |
5.82 |
| Total Q Factor (Qts) |
0.3 |
| Compliance Equivalent Volume (VAS) |
139.65Litr |
| Surface Area of Cone (Sd) |
830 |
| Reference Efficiency (o) |
4.35% |
| Voice Coil |
3.0” |
| Overhang (Xmax) |
2.5 mm |
| Moving Mass (Mms) |
80.31gm |
| BL Product (BL) |
20.49TM |
| Coil Inductance (Le) |
0.68mH |
| Overall Diameter |
395 mm |
| Depth |
160 mm |
| Baffle Hole Diameter |
358 mm |
| Bolt Mount Diameter (PCD) |
373 mm (8 Bolts) |
| Weight |
8.15kg |
