Very high sensitivity, excellent linearity and very low distortion. Very efficient heat dissipation in ensured by a radiator that is part of the basket design. The air is forced in the radiator thanks to a sealed spider design.

  • 3-inch, edgewound aluminum voice coil
  • 700W continuous program power handling
  • 100 dB Sensitivity
  • 40 Hz – 3 kHz Frequency range
  • Spider dampening treatment
  • M-roll surround and exponential cone geometry
Nominal Diameter 380 / 15 mm/inch
Rated Impedance 8 Ω
Program Power 700 W AES
Power handling capacity 350 W AES
Sensitivity 100 dB
Frequency Range 40 Hz ÷ 3000 Hz
Effective Piston Diameter 330/13 mm/inch
Max Excursion Before Damage (peak to peak) 36 / 1.4 mm/inch
Minimum Impedance 5.9 Ω
Voice Coil Diameter 76 / 3 mm/inch
Voice Coil Material Aluminum
Voice Coil Winding Depth 18 / 0.7 mm/inch
Number of layers 1
Kind of layer outside
Top Plate Thickness 10 / 0.4 mm/inch
Cone Material No pressed pulp
Cone Design Curved
Surround Material Polycotton
Surround Design M-roll
