The MB12X351 is designed to provide an excellent frequency response linearity with very low distortion. A very strong neodymium magnetic structure guarantee dynamic and precision, a new and unique 3,5” voice coil design provides a very high power handling, especially recommended in comparison to a standard 3” voice coil. The new dual forced hyper-venting system guarantee a very efficient voice coil ventilation for minimum power compression and incredible power handling.

  • 3.5-inch, fiberglass inside/outside copper voice coil
  • 1400W continuous program power handling
  • 98.5 dB Sensitivity
  • 45 Hz – 2.5 kHz Frequency range
  • Dual Forced Hyperventing System
  • Dual spider design with silicon based dampening control
Nominal Diameter 300 / 12 mm/inch
Rated Impedance 8 Ω
Program Power 1400 W AES
Power handling capacity 700 W AES
Sensitivity 98.5 dB
Frequency Range 45 Hz ÷ 2500 Hz
Effective Piston Diameter 260 / 10.2 mm/inch
Max Excursion Before Damage (peak to peak) 40 / 1.57 mm/inch
Minimum Impedance 7.1 Ω
Voice Coil Diameter 87 / 3.4 mm/inch
Voice Coil Material Copper
Voice Coil Winding Depth 19 / 0.74 mm/inch
Number of layers 2
Kind of layer inside / outside
Top Plate Thickness 10 / 0.39 mm/inch
Cone Material No pressed pulp
Cone Design Curved
Surround Material Polycotton
Surround Design M - roll
